NotePAC Pro

Compact rugged laptop with excellent performance and unrivaled connectivity. Configurable with the latest Intel® Xeon® processor.

Download Datasheet

Technical Specifications

Product	NotePAC Pro
Chassis Color	Light Gray
Display	17.3" FHD 1920x1080 Upgradable options: UHD 3840x2160, 60Hz Display, 2K, 144Hz displays
CPU	Intel® Xeon® D-2183IT
Memory	16GB DDR4 RAM, 2400 Upgradable to 32GB+
Graphics Card	NVIDIA Quadro P4000
OS Drive	512GB OS Drive
Storage	1TB Data Drive (Total of 4 removable hard drive cages)
Ports	Quad LAN with Intel® Ethernet Controller I350-AM4, Dual LAN with 10G SFP+ LAN via SoC, Dual LAN with 10Gbase-T, CAC reader
Power Supply	600W, 100~240 VAC External AC-DC Adapter; 6x 10.8V, 7,500mAh, 81Wh Batteries
Input	19VDC/31.6A
Output	19VDC
Charger Specs	Charging voltage: 19V ± 1V, Charging current: 13A ± 0.5A
Card Reader	CAC Reader
Dimensions	Height: 4.5" (114mm) Width: 16.75" (425.5mm) Depth: 12" (305mm)
Weight	~24lbs (10.9kg)
Expansion Slots	1x PCIe x8 Slot
Keyboard & Mouse	Backlit keyboard, available in a variety of languages
Quality	ISO 9001
Customization	Military connectors, custom I/O, and more.

Configuration Options

The technical specifications are an example of the system's capabilities. They can be customized specifically for your needs. If you have any questions, feel free to contact one of our sales representatives.

Contact Sales

Compare Similar Systems

At a glance, it may be difficult to see the differences among some of our products. As a result, simply click the button below to see the differences among other similar systems.

Product	NotePAC Pro	NotePAC Pro (Old)	NotePAC III
Display	17.3" FHD 1920x1080 Upgradable options: UHD 3840x2160, 60Hz Display, 2K, 144Hz displays	17.3" FHD 1920x1080 Upgradable options: UHD 3840x2160, 60Hz Display, 2K, 144Hz displays	3x 17.3" FHD 1920x1080 Upgradable options: UHD 3840x2160, 60Hz Display, 2K, 144Hz displays
CPU	Intel® Xeon® D-2183IT	Intel® Xeon® D-2183IT	Intel® Core™ i7-8700
Memory	16GB DDR4 RAM, 2400 Upgradable to 32GB+	16GB DDR4 RAM Upgradable to 32GB+	16GB DDR4 RAM, 2400 Upgradable to 32GB+
Graphics Card	NVIDIA Quadro P4000	Onboard graphics	NVIDIA Quadro P2000
OS Drive	512GB OS Drive	512GB OS Drive	512GB OS Drive
Storage	1TB Data Drive (Total of 4 removable hard drive cages)	1TB Data Drive (Total of 4 removable hard drive cages)	1TB Data Drive (Total of 4 removable hard drive cages)
Ports	Quad LAN with Intel® Ethernet Controller I350-AM4, Dual LAN with 10G SFP+ LAN via SoC, Dual LAN with 10Gbase-T, CAC reader	6x LAN	2x Gb LAN, Optional: 6x LAN, Video capture inputs, 3x HDMI external clone, CAC reader
Power Supply	600W, 100~240 VAC External AC-DC Adapter; 6x 10.8V, 7,500mAh, 81Wh Batteries	400W, Battery Option Available	400W, Battery Option Available
Input	19VDC/31.6A	N/A	N/A
Output	19VDC	N/A	N/A
Charger Specs	Charging voltage: 19V ± 1V, Charging current: 13A ± 0.5A	N/A	N/A
Card Reader	CAC Reader	CAC Reader	N/A
Dimensions	Height: 4.5" (114mm) Width: 16.75" (425.5mm) Depth: 12" (305mm)	Height: 5.8" (148mm) Width: 17.1" (435mm) Depth: 13" (330mm)	Height: 4.5" (114mm) Width: 16.75" (425.5mm) Depth: 12" (305mm)
Weight	~24lbs (10.9kg)	~20.4lbs (9.3kg)	~24lbs (10.9kg)
