HORUS430-X1


AI Inference GPU system supporting NVIDIA® GTX1080 (CUDA2560, 8GB GDDR5) and 9th Coffee-Lake I7-9850HE (6 Cores , 4.40GHz)

Download Datasheet

HORUS430-X1 Main
Video Preview

Introduction

Artificial intelligence (AI) is quickly becoming one of the most crucial components to business success now and in the foreseeable future. Today, the necessity of deploying powerful computing platforms that can accelerate and cost-effectively scale their AI-based products and services has become vital for successful enterprises.

7STARLAKE is innovating to address the rapidly emerging high-throughput inference market driven by technologies such as 5G, Smart Cities and IOT devices, which are generating huge amounts of data. The combination of NVIDIA Tensor RT and the new architecture based GeForce Accelerator as the ideal combination for these new demanding and latency-sensitive workloads and are aggressively leveraging them in GPU system.

Achieving the power of AI inference

Edge AI Inference GPU System

Intel Specs

With more threads and more cores, 9th Gen Intel® Core™ H-series processors for IoT bring high performance and connectivity to the edge—all in an efficient package with long-life availability that’s ideal for embedded use conditions. These processors are the first in the Intel® Core™ IoT family to offer up to eight cores, delivering dramatic improvements over the previous generation. New features include integrated graphics and even more robust connectivity to support the most demanding IoT use cases—all on the latest 14 nm technology. And with TDP ranges from 25W to 65W, form factors can vary without compromising performance.

Night Vision Mode Support

HORUS430-X1 is installed with graphics card NVIDIA GTX1080 (CUDA 2560,8 GB GDDR5X) , allowing generate excellent resolution and supports high efficiency and fluency of image processing with competitive G3D Mark and low power consumption. The GPGPU provides a simple and easily implementable parallel software architecture paradigm using general purpose programming languages like C / C++. The entire data / signal processing task can be realized as a sequence of software activities taking the advantage of very high throughput possible with the GPUs. The system possess great superiority for image computing utilization, including 2D/3D mapping and real-time image process for autonomous vehicle, surveillance system for control room, other navigation, radar, detection, sensor and laser systems on all maritime, ground, and aerial applications in both defense and industrial fields.

NVIDIA Specs

Unique Features

1. I/O Expansions

HORUS430-X1 is designed to fulfill demands of mission critical applications. Apart from standard I/O interface, HORUS430-X1 equipped with 4 x LAN, 4 x USB, 2 x DisplayPorts. With these rich interfaces, HORUS430-X1 can be easily applied to targeting & acquisition system to link with diversified sensors, such as thermal image camera, scanned array radar, etc.

2. Rugged D38999 Series connectors

D38999 connectors offer the highest performance capabilities and reliability for both general duty and severe environment applications. This cylindrical connector family designed for cable-to-panel I/O applications in military, aerospace and other demanding hazardous situations. D38999 connectors are capable of operation within a temperature range -65 to 200°C. They are lightweight and can stand up to environmental challenges. Made with removable crimp or fixed hermetic solder contacts, these connectors provide high-vibration characteristics and are suitable for severe wind and moisture problem areas.

3. MIL-STD-810G

HORUS430-X1 meets MIL-STD-810G for mechanical shock and vibration, it is designed and tested to withstand extended extended temperature (-20° to +55°C). Combining critical components soldering on board and solid connection, HORUS430-X1 is compliant to MIL-STD 810G standard, can withstand 5g vibration, 100g single shocks and 50g multiple shocks.

4. 300W Military Standard DC/DC Converter Module

SK711 is a wide input board type converter supporting input range from 18V to 36V. Possessing military standard filter for EMI avoidance, SK711 guarantees the stability of voltage and electric current for system operation, especially suitable for application in military or other harsh environment. Furthermore, with parallel design, two SK711 can be combined for double power of 300W, supporting prominent system performance. Compliant with MIL-STD 1275/461, extended operating temperature from -40 to 85°C, SK711 performs as an ideal converter module for severe environmental usage. The Cosel Hi-Rel DC/DC CONVERTER it also provides , Output Over Current Protection (OCP), Output Overvoltage Protection (OVP) and Over Temperature Protection (OTP) to made stability and safety.

Technical Specifications

Product HORUS430-X1
CPU Intel® 9th Coffee-Lake i7-9850HE (2.7 GHz, up to 4.4 GHz, 6-cores, 12 threads)
Memory DDR4-2666 Up to 64GB (ECC for Options)
Graphics Card NVIDIA MXM Graphic Card support up to GTX1080 (8GB GDDR5X, CUDA 2560)
Storage 2x mSATA, up to 1TB
Temperature (Operating) Low Temperature: MIL-STD-810G, Method 502.5, Procedure II,
(Operating) High Temperature: MIL-STD-810G, Method 501.5, Procedure II,
(Storage) Low Temperature: MIL-STD-810G, Method 502.5,
(Storage) High Temperature: MIL-STD-810G, Method 501.5 Procedure 1
Humidity (Operating) MIL-STD-810G, Method 507.5
Vibration (Operating) MIL-STD-810G, Method 514.6,
(Storage) MIL-STD-810G, Method 514.6
Shock (Operating) MIL-STD-810G, Method 516.6,
(Storage) MIL-STD-810G, Method 516.6
Customization Military connectors, custom I/O, and more.

Configuration Options

The technical specifications are an example of the system's capabilities. They can be customized specifically for your needs. If you have any questions, feel free to contact one of our sales representatives.

Contact Sales

Compare Similar Systems

At a glance, it may be difficult to see the differences among some of our products. As a result, simply click the button below to see the differences among other similar systems.

Product HORUS430-X1
CPU Intel® 9th Coffee-Lake i7-9850HE (2.7 GHz, up to 4.4 GHz, 6-cores, 12 threads)
Memory DDR4-2666 Up to 64GB (ECC for Options)
Graphics Card NVIDIA MXM Graphic Card support up to GTX1080 (8GB GDDR5X, CUDA 2560)
Storage 2x mSATA, up to 1TB
