HORUS428A
2U Fanless Storage Server, Intel® Xeon E3-1268L, 8 Bays 2.5" SAS RAID, 10GbE Support, NVIDIA®Quadro RTX 3000 GPU
Introduction
The rugged system HORUS428A powered by 6th Gen Intel® Xeon E3-1268L v5, i7-6700TE, which is designed and tested to meet the demand of a military level of ruggedness (MIL-STD-810G) and proven that the system are reliable (Anti-vibration & Shock, wide extended range operating temperature [0℃~50℃]) enough to operate under harsh environments. Also, the abundant I/O gives maximum flexibility on integrations and configurations with a wide variety of subsystems. Moreover, HORUS428A can build in Areca ARC-1226-8i SAS RAID Card supports up to 8 bays SAS/SSD drives. HORUS428A is a system with outstanding CPU performances, rich and functional I/O, and maximized ruggedness, and certainly improves a quality of all ground, maritime, and aerial operations.
Advanced CPU (6th Gen Intel® Xeon E3-1268L v5, i7-6700TE)
HORUS428A is applied with one of the newest CPU, 6th Gen Intel® Xeon E3-1268L v5, i7-6700TE which is a micro architecture using 14mn as same as its predecessor Broadwell. This 4 core 8 threads CPU runs at 2.4GHz clock speed as an average, yet it is able to process as 8 cores by the 8 threads architecture and accelerates up to 3.4 GHz by Intel® Turbo Boost Technology 2.0 during peak loads. As well as the incredible computing performance of Intel® 6th generation CPU.
Acme Portable specializes in developing ruggedized systems that support high resistance to shock and vibration, and wide range extended operating temperatures from subzero to unusual high temperature. In order to handle the high TDP of Intel® Xeon E3-1268L v5, i7-6700TE (35W), we apply a special thermal design to HORUS428A called "dual-sides thermal design". And three different types of thermal modules (copper heat-spreaders, liquid-vapor heat-pipes, aluminum heat-sink) are applied on each side to achieve effective and efficient heat dissipation on both right- and left-sides.
The Backbone of Rugged Server HORUS428A
The system main board AB20 is applied in HORUS428A has been developed by 7starlake which specializes in developing both ruggedized embedded boards and systems. This ruggedized ATX motherboard AB20 is powered by 6th Gen Intel® Xeon E3-1268L v5, i7-6700TE processor and supports rugged memory XR-DIMM 64GB DDR4 and abundant I/O interfaces. It is powerful and rugged enough to operate under harsh environments as military uses.
Technical Specifications
| Product | HORUS428A |
|---|---|
| CPU | 6th Gen Intel® Xeon E3-1268L v5, i7-6700TE |
| Graphics Card | NVIDIA® GTX 1050 Ti(CUDA Cores: 768), NVIDIA® RTX 2060S (CUDA Cores: 2176) |
| Memory | 4x DDR4 XR-DIMM up to 64GB |
| Expansion Slots | 4x mPCIe (two support with mSATA), 1x PICex4 |
| Storage | 8x 2.5" SAS HDD/SSD Tray |
| Dimensions | Width: 430mm, Depth: 377mm, Height: 88mm |
| Customization | Military connectors, custom I/O, and more. |
Configuration Options
The technical specifications are an example of the system's capabilities. They can be customized specifically for your needs. If you have any questions, feel free to contact one of our sales representatives.
Contact Sales| Product |
HORUS428A
|
|---|---|
| CPU | 6th Gen Intel® Xeon E3-1268L v5, i7-6700TE |
| Graphics Card | NVIDIA® GTX 1050 Ti(CUDA Cores: 768), NVIDIA® RTX 2060S (CUDA Cores: 2176) |
| Memory | 4x DDR4 XR-DIMM up to 64GB |
| Expansion Slots | 4x mPCIe (two support with mSATA), 1x PICex4 |
| Storage | 8x 2.5" SAS HDD/SSD Tray |
| Dimensions | Width: 430mm, Depth: 377mm, Height: 88mm |
