RS 100

Ideal portable GIS / weapons training platform

The RS 100 is the perfect platform for practicing and simulating real-life military experiences. The gunner can undergo combat situations to better prepare for the future.

It is a MIL-STD portable server designed for data acquisition, simulation, and training. The RS 100 is integrated with fully sealed Mil-Spec connectors and heavy-duty filters for the harshest of environments. Dual AC and DC power supply with redundant fail-over allows uninterrupted operations both in vehicles and in command tents. It has also been designed to operate in wide temperature ranges, extending its compatibility to more military applications.

Product RS 100
CPU 2x Intel Xeon E5-2640 V3, 2.6GHz, 20M cache, QPI up to 8 GT/s
RAM 64GB-DDR4, 2133MHZ (up to 128 GB)
GPU On-board Graphic with VGA up to 1920x1080, with 64GB shared memory
Storage 2x 1TB SSD, SATA III 6Gb/s (with 8x 2.5"HDD removable trays available)
USB 2x USB 3.0 ports , 2x USB 2.0 ports
Interfaces 1x COM port, 2x 10 Giga Lan ports, 2x AUDIO out
DVD-RW 1x DVD RW
Expansion Slots Low profile expansion slot supported: 1x PCIe 3.0 x16, 3x PCIe 3.0 x8, 1x PCIe 3.0 x4, 1x PCIe 2.0 x4
Operating System Varies per request
Dimensions Mechanism meets EIA/ECA-310, 19" Rackmount 2U, Depth: 500mm
Cabinet Mounting With fixed rear extend holder up to 600mm for (Std),
With Jonathan rails up to 600mm for (Options)
Environmental Specifications
Altitude MIL-STD-810G Method 500.5 Procedure II, 4572m, Functional
Operating Temperature MIL-STD-810G, Method 501.5
Storage Temperature MIL-STD-810G, Method 501.5, Procedure I (-40°C to 80°C)
Heat and Humidity MIL-STD-810G Method 507.5, 73 +/-4 F and 50 +/- 5% relative humidity
Vibration MIL-STD-810G, Method 514.6, Procedure I, Random General Vibration, Functional
Shock MIL-STD-810G, Method 516.6, Procedure I, Saw tooth wave, 20G/11ms, Functional
Compliance CE, FCC, RoHS
